# Networks and ColorInformation Visualization

## What We Are Going to Learn

• How to recognize, create, and store networks
• Network Visualization Techniques
• Force Simulations
• Matrix Representations
• Working with Color
• Sequential: one hue
• Divergent: two hues
• Categorical: Multiple hues
• Continuos multiple hues

# Networks: Basics

## Define Networks

Networks are defined by two things: nodes and links.

Nodes: a collection of entities which have properties that are somehow related to each other

• E.g., people, forks in rivers, proteins, web pages, organisms, etc.

• Links may be directed or undirected
• Links may be binary or weighted
[Slide courtesy of Andy Reagan]

## Just Some Examples

• Tournaments
• Organization charts
• Genealogy
• Diagramming (e.g., Visio)
• Biological interactions (genes, proteins)
• Computer networks
• Social networks
• Simulation and modeling
• Integrated circuit design
• River systems
• Many, many more (and some history)
[Slide courtesy of Andy Reagan]

## Network values

### Nodes

• Usually contains the values
• Friends attributes (name, age, gender, etc) in a social network.

• But links can also have attributes
• When the friendship was stablished
• What type of relationship
• How many friends in common do they have

### How to Store Network Data

[Slide courtesy of Andy Reagan]

[Slide courtesy of Andy Reagan]

### Node and Link Files (cont.)

[Slide courtesy of Andy Reagan]

[Slide courtesy of Andy Reagan]

### Nested: XML/JSON

[Slide courtesy of Andy Reagan]

### How to Create Network Data

• Group by common attribute.
[Slide courtesy of Andy Reagan]

### From Flat Data

Say we have tabular data for Les Miserables with columns for "scene", "character", and "line". We want to examine the network of which characters co-occur in scenes. Take all unique characters are nodes and link between all characters in a scene together.

• JS: d3.nest().key(function(d) { return d.scene; }).
• Python: pd.groupby('scene').
[Slide courtesy of Andy Reagan]

Social network data extract

• Loop through all of the messages.
• Add to a list of all users.
• Add to an edge list that has all "mentions" of another user.
[Slide courtesy of Andy Reagan]

## e.g. Co-authorship networks

https://observablehq.com/@john-guerra/uist-2020-co-authorship-network

# Networks: Force Simulations

### Idiom: Force-Directed Placement

• Visual encoding:
• Link connection marks, node point marks
• Explore topology; locate paths, clusters
• Scalability:
• Node/edge density E < 4N
• Considerations:
• Spatial position no meaning directly encoded
• Proximity semantics?

# Matrix Representations

• Data: network
• Transform into same data/encoding as heatmap
• Derived data: table from network
• One quantitative attribute
• Weighted edge between nodes
• Two categorical attributes: node list x 2
• Visual encoding:
• Cell shows presence/absence of edge
• Identify clusters (topology)
• Summarize topology/distribution
• Scalability:
• 1,000 nodes, one million edges

• Predictability, scalability, supports reordering
• Topology understanding, path tracing
• Intuitive, no training needed
• Empirical study:
• Node-link best for small networks
• Matrix best for large networks...
• ...if tasks don’t involve topological structure!

# Networks: Other Idioms

## Chord Diagram

• Data: networks (small number of nodes)
• Tasks: summarize connections; identify highest degree
• Considerations: usually good for origin to destination

## Edge Bundling

• Data: networks
• Considerations:
• Reduces cluttering
• Requires computing time
• Works with any link based idiom

## Arc Diagram

• Data: networks (few nodes)
• Considerations:
• Nodes' order matters.
• Better with highly clustered data

## Semantic Substrates

• Data: networks with many edges
• Task: summarize distribution of non network attribs
• Considerations:
• Easier to understand
• Scale well
• Edges on demand work best

## Idiom: Sankey Diagram

• Good for depicting flow
• Not that well-known

# Metrics and Statistics

### Simple Stuff

• Number of nodes, number of edges
• Connected components: count of separate groups of nodes
• Graph density: percent of possible links that are present

### Degree Distribution

• E.g., run “Average Degree” tab in Gephi
• For pure random networks: $P_k = e ^ { \langle k \rangle } \frac{ \langle k \rangle ^k}{k!}$
• For preferential attachment: $P_k ~\sim~ k ^ {-\gamma}$

### Path Length

• E.g., run “Average Path Length” in Gephi
• The path length between nodes i and j defined as $d_{ij}$
• Average path length $\langle d_{ij} \rangle$
• Network diameter $d_\max = \max _{i,j} d_{ij}$

### Centrality

• Betweenness centrality: number of shortest paths across node
• Degree centrality (node degree), also edge centrality (not in Gephi, use NetworkX)
• Eigenvector centrality $Ax = \lambda x$
• Closeness $d_{cl} = \left [ \sum _{ij} d_{ij} ^ {-1} / n \choose 2 \right ] ^ {-1}$

### More Centrality

• PageRank, like eigenvector centrality, can be written as an eigenvalue problem: $$PR(p_i) = \frac{1-d}{N} + \sum _{p_j} \frac{PR(p_j)}{L(p_j)}$$

### Clustering

• Watts and Strogatz measure: $$C_1 = \left \langle \frac{\sum_{j_1,j_2\in N} a_{j_1j_2}}{k_i(k_i-1)/2} \right \rangle$$
• Newman (and Gephi): $$C_2 = \frac{3 \times \textrm{triangles}}{\textrm{triples}}$$

# Color

### Decomposing Color

• First rule: do not talk about color!
• Color is confusing if treated as monolithic
• Decompose into three channels
• Ordered can show magnitude
• Luminance: how bright
• Saturation: how colorful
• Categorical can show identity
• Hue: what color
• Channels have different properties
• What they convey directly to perceptual system
• How much they can convey: how many discriminable bins can we use?

### Luminance

• Need luminance for edge detection
• Fine-grained detail only visible through luminance contrast
• Legible text requires luminance contrast!
• Intrinsic perceptual ordering

### Designing for Color Deficiency: Avoid Encoding by Hue Alone

• Redundantly encode.
• Vary luminance.
• Change shape.

### Categorical Color: Limited Number of Discriminable Bins

• Human perception built on relative comparisons
• Great if color is contiguous
• Suprisingly bad for absolute comparisons
• Noncontiguous small regions of color
• Fewer bins than you want
• Rule of thumb: 6-12 bins, including background and highlights

### Glyphs

• Glyphs: composite objects
• Internal structure with multiple marks
• Alternative to color encoding
• Or coding with any single channel

## Ordered Color

### Ordered Color: Rainbow is Poor Default

• Problems:
• Perceptually unordered
• Perceptually nonlinear
• Benefits:
• Fine-grained structure visible and nameable
• Alternative:
• Large-scale structure: fewer hues
• Fine structure: multiple hues with monotonically increasing luminance (vs. Viridis R/Python)

### Viridis

Colorful, perceptually uniform, colorblind-safe, monotonically-increasing luminance

# Map Other Channels

## What We Learned

• How to recognize, create, and store networks
• Network Visualization Techniques
